DURABLE EXTERIOR Hard coated polycarbonate lens offers long term scratch resistance ensuring maximum optical efficiency for years to come. UV stable AkzoNobel powder coat. polycarbonate lens and covers ensure long term durability.
BUILT TOUGH Pressure die-cast aluminium housing and strong. 4mm thick steel bracket will handle even the toughest tracks.
HIGH OUTPUT OSRAM LED’S 19 genuine. high output OSRAM LED’s for unmatched performance. 85W and 6.450 effective lumens per light.
MODERN ELECTRONICS DESIGN Built in Transistor switching simplifies wiring installation by removing the need for traditional 12V relays. PWM dimming capability for brightness control at the turn of a dial. (Wiring system sold separately)
SEALED TIGHT Waterproof and submersible. IP67 & IP69K rated with Genuine GORE breather. to manage the internal air pressure of the light.
ACTIVE TEMPERATURE CONTROL SYSTEM Intelligent onboard monitoring of the LED temperatures. combined with the superior cooling design allows for maximum output in all conditions.
SUPERIOR COOLING DESIGN Large air intakes channel cool air over the heatsink for unmatched cooling efficiency. allowing for the use of higher-powered LED’s.
LIGHTWEIGHT DESIGN Compact in size. weighing just 1.7kg. Perfectly suited to nudge bar. and alternative installations where size and weight restrictions apply.
CHANGEABLE BEAM PATTERN Clip on/clip off protective covers allow for quick changes between beam patterns. 1 x Spot. 1 x Flood included.
Power:
85W
Current Draw:
5.9A @ 14.4V
Voltage Range:
10 – 30VDC
LED Type:
19 x Genuine OSRAM LED’s
Luminous Flux:
6.450 lumens (effective)
Colour Temperature:
5700K
Power Plug:
Deutsch DT
Control Plug:
4 pin custom
(use with VLI Series Wiring System. sold separately)
Weight:
1.7kg
Compliance:
CE. UNECE R10. IP67. IP69K. ROHS
