A multi-circuit lighting reducer for 24V trucks towing trailers with 12V lamps. It provides five independent, current-limited 12V RMS outputs covering stop, tail, reverse and left and right indicator lamps, each driven by its own 24V control input from the truck's lighting circuits. It replaces the older VRB(REV), VRC and VRZ(REV) units. Backed by REDARC's 2-year warranty.
Key features
- Five 12V RMS channels: two 360W and three 180W
- Drives both incandescent and LED trailer lamps
- Soft-start on all channels for longer globe life
- Over 95 percent efficient, short-circuit and transient protected
- Sealed, electrically isolated case for commercial use
Specifications
| Part number | VRB5C |
| Brand | REDARC |
| Height | 75 mm |
| Width | 120 mm |
| Length | 295 mm |
| Input Voltage | 18 - 32V DC |
| Output Voltage | 12V RMS |
| Max. Rated Output Current | 31A |
| Input Fuse Rating | 80A |
Professional installation by an auto electrician is recommended.
